Suction: N/A
Discharge: 40mm / 1.5" (SV15), 65mm / 2.5" (SV25), 100mm / 4"
(SV40), 150 / 6" (SV60), 200 / 8" (SV80), 250 / 10" (SV100).
Maximum RPM: 2200 (SV15), 2000 (SV25), 1400 (SV40-900022), 1200 (SV40-901122), 1000 (SV60), 850 (SV80), 750 (SV100).
Sealing system: N/A
Liner material: High Chrome
Impeller material: High Chrome
Throat bush: N/A
Maximum motor power (kW): 15 (SV15), 30 (SV25), 75 (SV40), 110 (SV60), 110 (SV80), 200 (SV100).
Weight–Bare shaft pump (kg): 180 (SV15), 350 (SV25), 930 (SV40-900022), TBC (SV40-901122), 1737 (SV60), 1737 (SV80), N/A (SV100).
